Exposed Fastener System
System Depth = 1” + Universe Continuous Insulation System (1” to 3” thick as indicated on drawings)
Joint Width = 3/8”
Joint Width = 3/8”
System Components:
1. EQUITONE Panel
2. Universe Aluminum J-Extrusion – Black Color
3. Universe Aluminum Hat-Extrusion – Black Color
4. Extrusion Fastener
5. Panel Rivet – Color Matched
6. Foam Tape (Shop Attached)
7. Continuous Insulation Horizontal Wide-Faced Hat Extrusion Framing
8. Wide-Face Hat Framing Fastener; attaches through mineral wool to substrate
9. Roxul® ComfortBoard™ CIS 11# Density Mineral Wool Insulation
10. Air & Moisture Barrier
11. Sheathing
12. 16 Gauge Min. Steel Stud
2. Universe Aluminum J-Extrusion – Black Color
3. Universe Aluminum Hat-Extrusion – Black Color
4. Extrusion Fastener
5. Panel Rivet – Color Matched
6. Foam Tape (Shop Attached)
7. Continuous Insulation Horizontal Wide-Faced Hat Extrusion Framing
8. Wide-Face Hat Framing Fastener; attaches through mineral wool to substrate
9. Roxul® ComfortBoard™ CIS 11# Density Mineral Wool Insulation
10. Air & Moisture Barrier
11. Sheathing
12. 16 Gauge Min. Steel Stud
Notes:
• Vertically attached.
• The framing (7) is not painted.
• Insulation (9) must be Roxul® ComfortBoard™ CIS 11# Density mineral wool. Foam plastic insulation triggers NFPA-285 fire code which requires a tested assembly. The only other option is to acquire an AHJ approval. Receiving an AHJ approval is not guaranteed.
• Vertically attached.
• The framing (7) is not painted.
• Insulation (9) must be Roxul® ComfortBoard™ CIS 11# Density mineral wool. Foam plastic insulation triggers NFPA-285 fire code which requires a tested assembly. The only other option is to acquire an AHJ approval. Receiving an AHJ approval is not guaranteed.
